For the Ultimate Steel Well Tank, Look no Further!

Well-Rite is a no expense spared, equipped with the best of everything, ultimate well tank! In addition to its long list of premium features, Well-Rite is now equipped with a new antimicrobial liner on the lower half of the water chamber! In short, you get unmatched performance, superior air and water separation, and the purest water possible. It just doesn’t get any better than this!

Built with 16 gauge solid steel, finished with highest quality urethane paint to stand up to the dampest basement or crawl space. The water chamber is independent of tank walls, allowing diaphragms to be sized properly for each tank.

Product Details

Manufacturer: Flexcon Industries

Manufacturer Part Number: WR120R

Alternative Part Number: WR120

Application: POE (point-of-entry) for Residential or Cottage Use

Tank Volume: 33.4 Gallons / 100 Litres

Inlet Size: 1" NPT Stainless Steel

Diameter: 16 Inches (40.64 cm)

Height: 42.75 Inches (108.58 cm)

Total Weight: 49.00 LBS / 22.2 KG

Tank Construction: 16 Gauge Rolled Steel with High Pressure Seam Weld

Top Water Chamber: 100% Butyl Rubber

Bottom Water Chamber: Copolymer Polypropylene

Air Valve: Brass with O-Ring

Condensation Reducing Design Virtually Eliminates External Corrosion

Qualifies for Free Shipping

Canada Delivery Information Well-Rite WR120R

All Canadian Provinces - No Other Country

Ontario, Quebec, Nova Scotia

Alberta, British Columbia, Manitoba

New Brunswick, Prince Edward Island

Nunavut, Yukon & Northwest Territories

Saskatchewan, Newfoundland & Labrador

Rating Snapshot

Select a row below to filter reviews.

Average Customer Ratings

5.0

Reviews Sorting

Advice from Wahl

Perfect tank and parts required as recommended by the pros at Wahl. Very knowledgeable staff . Well-Rite pressure tanks are the leaders in the industry, this unit replaced my existing that lasted from 1996 .

Did you find this helpful? 1 of 1 Found Helpful

Reviewed by: (Verified Buyer) Clinton Roos from Mayo on 4/6/2023

Q: How much water can be draw on one charge with the 33.4 gallon WR120R

Asked by: Louis - 10/30/2019

A: It depends on the pressure your tank is set to, if you have it set for 40/60 psi the total Drawdown would be 9.7 Gallons or 36.8 Liters. If your tank is set to 30/50 psi it would be 11.3 Gallons or 42.6 Liters. The Quick Sizing Chart at the bottom of the Spec's Tab shows the Total Drawdown for all of the WR series tanks.

Was this answer helpful? 3 of 4 Customer(s) found this Answer helpful.

Answer provided by: Drew - Customer Service (10/30/2019)

Q: How tall is this tank and whats the diameter

Asked by: John - 2/21/2022

A: The height of the Flexcon WR120R Well-Rite Pressure Tank is 42.75 inches and the diameter is 16.0 inches according to the manufacturer's specifications which can be viewed on the spec's tab. Please contact us if you have any additional questions at 1-877-432-4117

Was this answer helpful? 1 of 1 Customer(s) found this Answer helpful.

Answer provided by: Jeff - Customer Service (2/21/2022)

Q: Does this tank come pre pressurized? also do you have controllers for this as well

Asked by: Rad - 4/21/2021

A: YES. This pressure tank comes with a pre charge air pressure of 38 psi from new. It can be adjusted if necessary to match the type of pressure with a pumping system. Controllers are generally associated with a pumping system and not a pressure tank. If this is what you are looking for, please contact us at 1-877-432-4117 for further assistance.

Was this answer helpful? 0 of 0 Customer(s) found this Answer helpful.

Answer provided by: Jeff - Customer Service (4/21/2021)

Q: I have a Wr120 OLC. Is this the same tank?

Asked by: Peter Duller - 3/15/2022

A: Assuming that the manufacturer is Flexcon Industries then YES this is the same tank as the model numbers have changed over the years however the dimensions of the tank have remained essentially the same.

Was this answer helpful? 0 of 0 Customer(s) found this Answer helpful.

Answer provided by: Jeff - Customer Service (3/15/2022)

Q: Hi, I have this tank in my crawlspace, the air valve has water pouring out of it. I’m guessing this means the bladder has failed? It is mounted horizontally, this tank is designed to be mounted vertically? Should the new tank be mounted vertically so the bladder does not fail again? This tank is 2 years old. Thank you for any suggestions.

Asked by: Andy - 3/31/2022

A: The Well-Rite series pressure tanks are designed to be installed vertically. From new the tanks come with a 5 Year Bladder Warranty assuming they are installed correctly. When water comes out of the air valve in a pressure tank, it means that the interior bladder separating the pre-charge air and water inside the tank has ruptured. A replacement tank is required when this has occurred.

Was this answer helpful? 0 of 0 Customer(s) found this Answer helpful.

Answer provided by: Jeff - Customer Service (4/1/2022)

Q: Ours drains at night sometimes. What causes that.

Asked by: Bill Smith - 9/10/2022

A: Water drains from a pressure tank when there is a demand for water on the outlet side of the tank. This can be from various sources such as a water softener, backwashing filter entering regeneration or a reverse osmosis system making water. Since this is not occurring every night, this is likely the source of water draining from the tank assuming there is a one of these units installed in your home.

Was this answer helpful? 0 of 0 Customer(s) found this Answer helpful.

Answer provided by: Jeff - Customer Service (9/11/2022)
